ATEQ_VIC_helium_He-490M

HIGHLIGHTS

  • Industry’s most sensitive and accurate leak detection
  • Reliable
  • Rugged with many systems operating for 20 years
  • Easy to maintain
  • Fast response time
  • Portable
  • Password Protection prevents unauthorized access
  • Helium mass spectrometer is a least 1000 times more sensitive than other leak detection methods

He-490M – HELIUM LEAK DETECTOR

TURNKEY VACUUM MASS SPECTROMETER SYSTEMS

The He-490M is a turnkey vacuum mass spectrometer system characterized by ease of maintenance and adaptability to system use. The He-490M uses the most sensitive and accurate method of leak detection: the helium mass spectrometer. The He-490M meets the stringent requirements for robustness, reliability and ease of maintenance that are essential in any industrial environment..

He-490M: APPLICATIONS

AUTOMOTIVE

  • Air Conditioning
  • Radiators
  • Exhaust
  • Transmission…

EMOBILITY

  • Battery Packs
  • Pouches & Cells
  • Modules
  • Housing…

PACKAGINGS

  • Aerosol Caps
  • Plastic Bags
  • Sprays
  • Plastic Bottles…

ELECTRONICS

  • Hard Disk
  • Watches
  • TV Screen
  • Camera Lenses…

MEDICAL

  • Blister Packs
  • Fluid Bags
  • Filters
  • Condoms…

He-490M: FEATURES

Performance

  • Sensitivity: System Mode, minimum detectable helium leak rate 2.5 x 10-9 atm-cc/sec.
    Sniffer Mode, minimum detectable helium leak rate 2.5 x 10-7 atm- cc/sec.
  • Response Time: < 1.0 second system mode testing, < 1.5 seconds sniffer mode testing.
  • Startup Time: One button automatic operation.
    Cold Start-Up, less than 3 minutes.
    Standby Start-Up, less than 1 minute

Display Leak Rate Range

  • System Mode Testing: 0-10 Volts output to main PLC. Leak rate configured to systems calibrated gas leak.
  • Interface Signals: Auto-Zero, Ready, Leak Rate and Fault Signals.
  • Sniffer Mode Testing: 10-3 to 10-7 atm-cc/sec He direct-reading.

Main Features

  • Cold Start-Up, less than 3 minutes
  • Standby Start-Up, less than 1 minute
  • One button automatic operation
  • Hard vacuum leak detection system
  • Modular assembly for custom arrangement
  • PLC controlled
  • Turn-key operation
  • Front panel key lock-out
  • Turbo speed adjustable from 600 to 1500HZ
  • Five year warranty on major components
  • Includes an internal fast clean-up sniffer manifold
  • Allows rapid switching between sniff and vacuum testing modes
  • Auto peak cycle
He-490M: OPTIONS

Options

  • 24Vdc control
  • 110Vdc control
  • Atmospheric sniffer module
  • Side mount configuration
  • Bottom mount configuration
  • Electrical Converter Box
ATEQ_He-490M

A standardized solution for thermal leak testing equipment. The Scepter is offered as a single, dual or IHX configuration

He-490M: SPECIFICATIONS
Technical Specifications
Power 115/220 Volts AC, 60/50 Hz, 4 Amps
(other voltages available upon request)
Dimensions Dimensions (in mm)
W344*H395*D618
Valve High vacuum rated solenoid actuated fore-line isolation
Pressure Measurement Connection gage for rough vacuum (atm-10-3 Torr),Turbo pump speed characteristics for high vacuum (10-6 Torr)
Inlet System External PLC controlled valves, externally mounted. Options: DC or AC
High Vacuum Pump 53 c/second air-cooled turbo-molecular
Mechanical Pump External forepump arrangement, standard package with 7 CFM
leak-rate-signal_He-490M
He-490M : FACTSHEETS

Detailed information about the He-490M including features, specifications, etc.
